Dell Broadcom 57414 24GFD 2-Port 25Gbit 25 GbE/ 10 GbE SFP28 PCIe Network Card
$89.00
Availability:
In Stock
Dell Broadcom 57414 24GFD 2-Port 25Gbit SFP28 PCIe Network Card
The Dell Broadcom 57414 Dual-Port 10/25 GbE SFP28 Adapter is a high-performance network card designed for enterprise servers, delivering two 25 Gbps SFP28 ports with backward compatibility to 10 GbE. It uses a PCIe 3.0 x8 interface and supports advanced networking features including jumbo frames, hardware offloads, SR-IOV, PXE boot, and virtualization acceleration—ideal for data-center workloads, virtualization, and high-speed server interconnects.
Dell Broadcom 57414 24GFD 2-Port 25Gbit SFP28 PCIe Network Card
General
| Specification | Details |
|---|---|
| Product Name | Dell Broadcom 57414 Dual-Port 10/25 GbE SFP28 Adapter |
| Controller | Broadcom BCM57414 Ethernet Controller |
| Form Factor | PCI Express network card |
| PCIe Interface | PCIe 3.0 x8 (host interface) |
| Bracket Options | Full-height or Low-profile (depending on SKU) |
Networking
| Specification | Details |
|---|---|
| Network Standards | 10 Gigabit Ethernet, 25 Gigabit Ethernet |
| Ports | 2 × SFP28 |
| Supported Speeds | 25 Gbps per port (native), backward support for 10 GbE |
| Data Link Protocol | 25 GbE / 10 GbE Ethernet |
| Aggregate Bandwidth | Up to 50 Gbps total (full duplex) |
