HP NC560SFP 560SFP+ 10GbE SFP+ Dual Port PCI-e NIC X520-DA2 669279-001
$35.00
Availability:
In Stock
HP NC560SFP 560SFP+ 10GbE SFP+ Dual Port PCI-e NIC X520-DA2 669279-001
The HP 560SFP+ Adapter is a dual-port 10 Gigabit Ethernet SFP+ PCIe x8 network card powered by the Intel 82599 controller. It provides two 10 GbE ports, advanced offloads, VLAN support, jumbo frames, and virtualization-friendly features, making it ideal for enterprise servers, virtualization hosts, and data-center workloads. Both standard and low-profile brackets are included for flexible installation.
HP NC560SFP 560SFP+ 10GbE SFP+ Dual Port PCI-e NIC X520-DA2 669279-001
General
| Specification | Details |
|---|---|
| Product Name | HP Ethernet 10Gb 2-port 560SFP+ Adapter |
| Model / Part Numbers | 665249-B21, 669279-001 |
| Controller | Intel® 82599 10-Gigabit Ethernet Controller |
| Form Factor | PCI Express add-in card |
| PCIe Interface | PCI Express 2.0 x8 |
| Bracket | Standard & Low-profile included |
Networking
| Specification | Details |
|---|---|
| Network Standard | 10 Gigabit Ethernet |
| Data Link Protocol | IEEE 802.3, IEEE 802.1Q (VLAN), IEEE 802.3x (Flow Control), IEEE 802.3ae (10GbE) |
| Ports | 2 × SFP+ |
| Supported Speeds | 10 Gbps per port (full duplex) |
| Aggregate Bandwidth | 40 Gbps (full duplex total) |
